Selective drift correction with ignore rules

Let external controllers like HPA and cert-manager manage specific fields without fighting Flux drift correction.
By Dipti Pai |
Tags:

We are excited to introduce drift ignore rules for Flux Kustomizations, a long-requested capability that lets you tell Flux to leave specific fields alone during drift detection and correction, while continuing to reconcile everything else.

One of the core promises of GitOps with Flux is continuous reconciliation: the kustomize-controller runs a periodic server-side apply dry-run to detect drift between the desired state in Git and the live state in the cluster, and corrects any divergence. This is exactly what you want for most fields; it guarantees that the cluster always matches the source of truth and that manual kubectl edits are reverted.

But not every field on a Kubernetes object should be owned by Flux. In real clusters, other controllers legitimately mutate parts of the resources that Flux manages, and Flux’s drift correction ends up fighting them on every reconcile.

The problem: when drift correction fights other controllers

Consider a Deployment that Flux reconciles from Git with replicas: 2. You also run a HorizontalPodAutoscaler that scales the workload to 5 replicas under load. On the next reconciliation, Flux sees the live replicas: 5 as drift from the desired replicas: 2 and scales the Deployment back down, undoing the autoscaler. The HPA scales it back up, Flux scales it back down, and the two controllers ping-pong indefinitely.

I ran into a memorable variant of this myself. On a small cluster, an HPA had been configured with a minReplicas floor well below the replica count baked into the GitOps manifest. Every time Flux reconciled, it bumped the Deployment back up to the manifest’s much higher replica count. That surge was enough to exceed the cluster’s capacity, so the cluster autoscaler dutifully spun up a brand new node to schedule the extra pods. Moments later, the HPA scaled the Deployment back down to its minReplicas floor, the new node went idle, and the autoscaler tore it down again. Reconcile, scale up, add node, scale down, remove node, repeat, on every interval. What should have been a quiet steady state turned into constant node churn and a SEV2 incident.

The same pattern shows up with many other tools:

  • cert-manager’s cainjector writing the caBundle into a CRD conversion webhook.
  • An operator that owns a single key inside a ConfigMap while Flux owns the rest.

Until now, the options were coarse: disable drift correction for the whole Kustomization, or exclude the entire resource from reconciliation. Both throw away the safety that GitOps gives you for all the other fields on those objects.

Drift ignore rules solve this at the field level.

Introducing .spec.ignore

The Kustomization API now has an optional .spec.ignore list. Each rule combines a set of JSON Pointer (RFC 6901) paths with an optional target selector that scopes the rule to specific resources:

---
apiVersion: kustomize.toolkit.fluxcd.io/v1
kind: Kustomization
metadata:
  name: app
  namespace: flux-system
spec:
  interval: 10m
  prune: true
  sourceRef:
    kind: GitRepository
    name: app
  ignore:
    - paths:
        - "/spec/replicas"
      target:
        kind: Deployment

With this rule in place, Flux ignores /spec/replicas on all Deployments during drift detection and correction, allowing an HPA to own the replica count, while still correcting drift on every other field (image tags, environment variables, labels, and so on).

The target selector supports group, version, kind, name, and namespace (all matched as regular expressions), as well as labelSelector and annotationSelector using standard Kubernetes selector syntax. If you omit target, the rule applies to all resources managed by the Kustomization, so it is good practice to always scope rules to the resources you intend.

Tip: For JSON Pointer paths that contain a / in the key name, the / must be escaped as ~1. For example, the annotation example.com/config-hash is referenced as /metadata/annotations/example.com~1config-hash.

How it works

Drift ignore rules build on the Kubernetes server-side apply field ownership model. When a reconciliation is triggered, for each ignored path the controller resolves one of two strategies based on who owns the field:

  • Strip: if the ignored field is owned by another server-side Apply field manager, Flux removes the field from its apply payload. This relinquishes Flux’s ownership and lets the other field manager keep full control of the field.
  • Adopt: if Flux is the sole Apply-type field manager for the field, the in-cluster value is copied into the apply payload. This preserves the current value, even after a kubectl patch or kubectl edit, without Flux reverting it and while keeping Flux’s field ownership intact.

A key property is that changes to ignored fields alone do not trigger a reconciliation. The controller excludes ignored paths when comparing the desired state against the live object, so a modification made by an external controller to an ignored field will not cause an unnecessary apply or a resource version bump.

An ignore rule is not just about sharing ownership after the fact: because the value committed to Git is applied when the object is first created, it also lets Flux seed an initial value that another controller then takes over. Flux sets the field on the first apply, and once another controller writes to it, Flux steps back and preserves that value on every subsequent reconciliation.

Real-world examples

Let an autoscaler own replicas

The canonical use case: hand replicas over to a HorizontalPodAutoscaler.

spec:
  ignore:
    - paths:
        - "/spec/replicas"
      target:
        kind: Deployment
        name: podinfo

If the HPA scales podinfo from 2 to 5 replicas, Flux leaves the count at 5. If you also bump the container image in Git, Flux still corrects the image; the ignore rule only protects replicas.

This also improves on the long-standing guidance of omitting replicas from Git so Flux would not fight the autoscaler: an omitted field defaults to 1, so a fresh rollout starts at a single replica until the HPA scales it up. With an ignore rule you can instead commit a sensible starting value, for example replicas: 10. Flux seeds that value when the Deployment is first created, and the HPA takes over from there.

Let cert-manager inject a webhook CA bundle

cert-manager’s cainjector populates the caBundle field of webhook configurations and CRD conversion webhooks, triggered by the cert-manager.io/inject-ca-from annotation. caBundle is an optional base64 field whose real value cert-manager owns at runtime. If the CRD is committed to Git with an explicit empty caBundle: "", Flux and cainjector end up toggling the field against each other on every reconcile, rewriting the object each time. Ignore the caBundle path so cainjector keeps control:

spec:
  ignore:
    - paths:
        - "/spec/conversion/webhook/clientConfig/caBundle"
      target:
        group: apiextensions.k8s.io
        kind: CustomResourceDefinition
        name: widgets.example.com

Combine multiple rules

Rules compose, so you can cover several resources in a single Kustomization:

spec:
  ignore:
    - paths:
        - "/spec/replicas"
      target:
        kind: Deployment
        name: podinfo
    - paths:
        - "/spec/conversion/webhook/clientConfig/caBundle"
      target:
        group: apiextensions.k8s.io
        kind: CustomResourceDefinition
        name: widgets.example.com
    - paths:
        - "/data/managed-by-operator"
      target:
        kind: ConfigMap
        name: app-config

Preview changes with flux diff

The Flux CLI honors the ignore rules too. Running flux diff kustomization gives you an accurate preview that matches what the controller will actually do, so ignored fields are not reported as spurious diffs:

flux diff kustomization my-app --path ./path/to/local/manifests --kustomization-file ./path/to/local/my-app.yaml

Notes and limitations

  • Drift ignore rules are designed to work with the server-side apply field ownership model. They are the right tool for delegating fields to other controllers that legitimately manage them (such as HPA and cert-manager).
  • Always scope rules with target unless you genuinely want to ignore the given paths across every resource in the Kustomization.
  • Because ignored fields are excluded from drift comparison, Flux will not update an ignored field even when its value changes in Git while another controller owns it. The field is intentionally delegated.

Wrapping up

Drift ignore rules close a long-standing gap: you no longer have to choose between full GitOps drift correction and coexisting with autoscalers and other field-level controllers. You get both: Flux keeps the cluster aligned with Git for everything you declare, and steps back from the specific fields you delegate.

This capability landed across several Flux components:

For the full reference, see the Ignore Rules section of the Kustomization documentation. As always, we would love to hear your feedback. Join us on the CNCF Slack or open an issue on GitHub.
